3.7V 58Ah Prismatic NCM Lithium Ion Battery Cell

Battery type: Lithium Ion Cell(NCM)
Model: NCM58
Nominal voltage: 3.7V
Nominal capacity: 58Ah
Energy Density 244(Wh/kg)
Charge cut-off voltage: 4.2V
Discharge cut-off voltage: 2.75V
Standard Charge Current 29A
Max charge current: 58A
Max Continuous discharge current: 174A
Peak discharge current: 290A(<3S)
Charge temperature: -20~55℃
Discharge temperature: -30~55℃
Storage temperature 0~60℃
Internal Resistance: ≤0.6±0.1mΩ
Cycle life: >1000 times
Weight: Approx 860±15g
Dimension(L*W*H): 148.2*26.72±0.2*95.21±0.3mm
Terminal: M6*10mm

The application of li-ion cell:
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts, Electric Forklifts

The feature of li-ion cell
1. Long cycle life
2. Safe, Stability
3. No leakage, explosion-proof, environmentally friendly
