Battery type: | Lifepo4 Battery |
Battery model: | VP-LF24-24 |
Nominal voltage: | 25.6V |
Nominal capacity: | 24Ah |
Charge cut-off voltage: | 29.2V |
Discharge cut-off voltage: | 16.0V |
Maximum charge current: | 5.0A |
Continuous discharge current: | 24.0A |
Maximum discharge current: | 48.0A(<3S) |
Charge temperature: | 0~45℃ |
Discharge temperature | -20~60℃ |
Cycle life: | >2000 cycles @100% DOD,1C charge/discharge |
Weight: | Approx 6.8Kg |
Dimension: | 320mmx72mmx158mm/custom |
BMS: | Over voltage, over current, short circuit, temperature protection, cell balance |
This 24V 24Ah LFP battery system has built-in BMS
1. Long cycle life (more than 2500 cycles at 100% DOD) .
2. Built-in smart BMS with multiple protection and communication functions.
3. Wide working temperature range and high reliability.
4. Multiple battery units can be connected in parallel, suitable for high-energy storage applications.
5. Compatible with various charge controllers and inverters.
6. Application: Electric Bike, Electric scooter, Lawn mower, Electric wheelchair, etc.
