Customized Li-Ion 36V 28AH 10S8P 18650 Battery Pack WIth PVC Case

Battery Brand VCELL/OEM
Battery Type Lithium-ion Battery(NCM)
Model 18650-10S8P
Nominal Voltage 36V
Nominal Capacity 28Ah
Charge Cut-Off Voltage 42V
Discharge Cut-Off Voltage 27.5V
Standard charge current 2A
Max charge current 5A
Max continuous discharge current 50A
Peak discharge current 150A(<3S )
Fit Motor 250W-1200W
Charge temperature 0~45℃
Discharge temperature -20~60℃
BMS Overcharge/discharge, over current, short circuit, temperature protection, cell balance
Size 200*160*70mm Max (can be customized)
Weight 4.1Kg Approx
Cycle life >700
Wire/Connector TBD

36V 28Ah Li-Ion Battery Pack
Features:
1. High energy density
2. High working voltage for single battery cells
3. Pollution-free, environment friendly
4. Long cycle life, cycle life up to 700 cycles
5. Capacity, resistance, Voltage, and consistency are good
6. Built-in BMS, safe and reliable
7. Factory price & High quality
8. Light weight, small size

Applications: Electric Bike, Golf cart, Electric Scooter, electric skateboard, power wheelchair, etc
