Battery Brand | VCELL/OEM |
Battery Type | Li-Ion Battery(NCM) |
Model | 18650-16S8P |
Nominal Voltage | 60V |
Nominal Capacity | 28Ah |
Charge Cut-Off Voltage | 67.2V |
Discharge Cut-Off Voltage | 44.8V |
Standard Charging Current | 2A |
Max charge current | 5A |
BMS | 35A |
Max continuous discharge current | 35A |
Peak discharge current | 65A |
Match Motor Power | 250W-1000W |
Charge temperature | 0~45℃ |
Discharge temperature | -20~60℃ |
Size(L*W*H) | 310*165*70mm Max |
Weight | 5.4Kg Approx |
Cycle life | >700 |
Wire/Connector | TBD |
This battery is made of 16S8P lithium-ion cells, long cycle life, and built-in BMS, which prevents the battery from overcharging, over-discharge, short circuits, and has temperature protection, cell balance functions, safe, stable, and non-polluting. Widely used for e-bikes, electric tricycles, electric scooters, etc.
