48V 150AH LiFePo4 Battery For UPS

Battery type: Lifepo4 Battery
Battery model: VP-LF48-150U
Nominal voltage: 48V
Nominal capacity: 150.0Ah
Charge cut-off voltage: 54.75V
Discharge cut-off voltage: 37.5V
Charge current: 75.0A
Discharge current: 100.0A
Cycle life: >2500 cycles @100% DOD,1C Charge/Discharge
Weight: Approx 60.0Kg
Dimension: 480*550*177mm
BMS: Over voltage, over current, short circuit, temperature protection, cell balance
Communication: RS485/RS232

Vcell provides safe, well-designed and high-performance stanard LFP battery pack. The battery pack is compact, easy to install, free of maintenance and can be installed in parallel in the energy storage system to increase its capacity. It is widely applied in residential applications, small commercial and industrial energy storage systems,UPS.

Advantages

This 48V 150Ah LFP battery system has built-in BMS and stainless steel box painted in black.

1. Long cycle life (more than 2500 cycles at 100% DOD) .

2. Built-in smart BMS with multiple protection and communication functions.

3. Wide working temperature range and high reliability.

4. Multiple battery units can be connected in parallel, suitable for high-energy storage applications.

5. Compatible with various charge controllers and inverters.
