Battery Brand | VCELL/OEM |
Battery Type | LiFePO4 battery |
Model | VP-LF48-120 |
Nominal Voltage | 51.2V |
Nominal Capacity | 120.0Ah |
Charge Cut-Off Voltage | 58.4V |
Discharge Cut-Off Voltage | 32.0V |
Standard charge current | 50A |
Max charge current | 120A |
Max discharge current | 120A |
Peak discharge current | 400A(<3S ) |
Charge temperature | 0~45℃ |
Discharge temperature | -20~60℃ |
BMS | Overcharge/discharge, over current, short circuit, temperature protection, cell balance |
Communication Ports | RS485/232, CANBUS |
Size(D*H) | 790*300*260mm |
Weight | 60Kg Approx |
Cycle life | >2500 |
Display | Optional |
Bluetooth | Optional |
Battery advantages:
1. VCELL 48V120Ah LFP battery, built-in smart BMS with multiple
2. protection and communication functions
3. With a stainless steel box, maintenance-free, modular design for easy installation and capacity expansion.
4. Long cycle life, wide working temperature range.
5. Compatible with various charge controllers and inverters.
6. Widely used for AGV, forklift, electric car, sweeper, RV, caravan, off-grid solar system storage, telecom back-up, central data center, etc.
