24V 50Ah Deep Cycle LiFePo4 Battery For AGV
| Battery type: | LiFePo4 Battery |
| Battery model: | VP-LF24-50U |
| Nominal voltage: | 25.6V |
| Nominal capacity: | 50.0Ah |
| Cell type | 26650 3.2V 3300mAh 8S15P |
| Charge cut-off voltage: | 28.8V |
| Discharge cut-off voltage: | 20.0V |
| Max charge current: | 30.0A |
| Max continuous discharge current: | 30.0A |
| Peak discharge current: | 90.0A |
| Cycle life: | >2000 cycles @100% DOD,1C Charge/Discharge |
| Weight: | Approx 19Kg |
| Dimension: | 330*310*120mm L*W*H |
| BMS: | Over voltage, over current, short circuit, temperature protection, cell balance |
This 24V 50Ah LFP battery system has built-in BMS and stainless steel box painted in black.
1. Long cycle life (more than 2500 cycles at 100% DOD) .
2. Built-in smart BMS with multiple protection and communication functions.
3. Wide working temperature range and high reliability.
4. Multiple battery units can be connected in parallel, suitable for high-energy storage applications.
5. Compatible with various charge controllers and inverters.
6. Application: E-car, E-bus, Golf trolley/ car, E-bike, Scooter, RV, AGV, Marine, Tourist car, Caravan, Solar-Wind Power System, City Grid (On/Off) Back-up solar System and UPS, Telcom Base, CATV system, Computer Server Center, Medical Instrument, Military Equipment Other Applications, etc.
